Forming · High capacity
CXJ600 High-Capacity Forming Machine
For industrial lines that need 500–1000 kg/h. Four-screw feeding reduces shearing of the raw material for better texture and stable quality.
- Capacity 500–1000 kg/h
- 15–60 strokes/min
- Thickness 6–40 mm
- Weight error ≤1%
Overview
The CXJ600 automatic multi forming machine performs filling, forming and discharging automatically. It uses a four-screw feeding system that greatly reduces cutting of the raw material, giving high output and stable quality.
Moulds change quickly, and accurate portioning keeps raw material cost under control. It handles meat, poultry, fish and shrimp as well as potato and other tuber mixes, and connects to batter applicators, predusters, fryers, cookers, freezers and packing machines to build a fully automatic prepared food line.
Key features
Four-screw feeding
Less shearing of the raw material for better bite and texture.
High output
500–1000 kg/h at 15–60 strokes per minute.
Large products
Up to 150 mm diameter and 6–40 mm thickness.
Accurate portions
Weight error of 1% or less.
Quick mould change
Switch products fast with easy mould replacement.
Safety
Magnetic protection switch on the safety cover.
Technical specifications
| Item | CXJ600 |
|---|---|
| Belt width | 600 mm |
| Capacity | 500–1000 kg/h |
| Speed | 15–60 strokes/min |
| Product thickness | 6–40 mm |
| Max. product diameter | 150 mm (burger patty) |
| Weight error | ≤1% |
| Filling pressure | 3–15 MPa |
| Air / water pressure | 6 bar / 2 bar |
| Power | 15.12 kW |
| Dimensions (L×W×H) | 3170×1176×2636 mm |
Applications
Suitable for minced and sliced materials:
- Burger patties up to 150 mm
- Chicken nuggets and cartoon shapes
- Fish and shrimp patties
- Hash browns, onion rings and squid rings
Where it fits in your line
The CXJ600 heads a 600 mm high-capacity coating line.
- Bucket lifter
- CXJ600 forming
- SFJ600 preduster
- Batter applicator
- Breading machine
- Continuous fryer
- Freezing and packing
Options and customization
- Custom moulds
- Custom voltage
Delivery, warranty and service
| Item | Details |
|---|---|
| Lead time | Confirmed with quotation. |
| Voltage | 380 V / 50 Hz standard; other voltages on request |
| Warranty | 12 months |
| Packing | Export wooden case; fumigated for shipments to Europe |
| Payment | T/T 30% deposit, 70% before shipment |
| Service | Remote support, spare parts, on-site installation and training on request |
FAQ
What is the difference between the CXJ400 and the CXJ600?
The CXJ600 has a 600 mm belt, 500–1000 kg/h capacity and four-screw feeding, and forms products up to 150 mm diameter and 40 mm thick. The CXJ400 has a 400 mm belt and 200–600 kg/h.
Why does four-screw feeding matter?
It reduces cutting and shearing of the raw material, which helps keep a natural meat texture.
Can it make burger patties for quick service restaurants?
Yes. It forms patties up to 150 mm diameter with a weight error of 1% or less.
